1. Product Features
• One-Piece Body: Eliminates potential leak paths for maximum reliability
• Threaded Ends: NPT or BSPP connections for easy installation
• Compact Design: Space-saving construction for tight installations
• Low Torque Operation: Smooth 90° handle rotation
• Fire-Safe Option: Available with metal seats (API 607 compliant)
2. Key Advantages
• Economical Solution: Cost-effective without compromising quality
• Minimal Maintenance: Self-lubricating seats for long service life
• Versatile Applications: Suitable for liquids and gases
• Lightweight Construction: Easy to handle and install
• Reliable Sealing: Double-sealed stem design
3. Technical Parameters
| Parameter | Specification |
|---|---|
| Body Material | 304SS, 316SS, WCB |
| Pressure Rating | 150# (1000 WOG) |
| Temperature Range | -20°C to 150°C (PTFE seats) |
| Connection Type | NPT, BSPP, BSPT |
| Size Range | 1/4" to 2" (DN8 to DN50) |
| Handle Type | Lever or Round Knob |
| Seat Material | PTFE, RPTFE, Metal (optional) |
4. Applications
• Water supply and distribution systems
• Compressed air and gas lines
• Chemical processing equipment
• HVAC and refrigeration systems
• Instrumentation and control piping
• General industrial process lines
5. Quality Certifications
• ISO 9001: Quality Management System Certified
• Test Standards: API 598, BS EN 12266-1
6. Optional Features
• Locking handle for security
• Bleed port for pressure release
• Extended stem for insulated lines
• Anti-static device (for flammable media)
• Special packaging for export
7. Service Benefits
• Standard stock availability
• Custom marking/labeling available
• OEM packaging solutions
• Technical support for product selection
