1. Key Advantages
Zero Leakage Seal
- Hard alloy sealing surfaces (e.g. Stellite cobalt-based overlay welding), wear-resistant, high temperature resistant, in accordance with ISO 5208 standards, bearing pressure up to 16MPa.
Fast opening and closing
- Stem lifting design, short opening and closing stroke, labor-saving operation (handwheel or electric drive optional).
Long life
- 316L stainless steel stem + PTFE packing, resistant to high-frequency operation (more than 5 million times), maintenance-free design.
Multi-scenario adaptation
- Horizontal/vertical pipeline installation, suitable for chemical, food, pharmaceutical, energy and other industries.
2. Technical Specifications (Technical Specifications)
|
Parameter items |
Standard configuration |
Extended options |
|
Body Material |
304/316 Stainless Steel |
316L (Medical Grade), Alloy Steel |
|
Thread Standard |
G (BSPP), R (BSPT), NPT (AFSL) |
Customized Special Threads (e.g., UNF) |
|
Pressure Rating |
PN16 (Standard) |
PN25/PN40 (high pressure type) |
|
Temperature range |
-20℃~+200℃ |
+350℃ (high temperature customized type) |
|
Sealing material |
PTFE/flexible graphite |
metal hard seal (high temperature high pressure) |
|
Drive method |
manual (handwheel) |
electric/pneumatic (explosion-proof) |
|
Certification standard |
ISO 9001, FDA |
3-A, ASME BPE (Biopharma) |
3. Industry Applications
Chemical/Petroleum
- Petroleum piping, chemical delivery (hydrogen sulfide corrosion resistant).
Food & Beverage
- CIP cleaning systems, dairy piping (sanitary polish, FDA approved).
Pharmaceutical/Bioengineering
- Purified water systems, bioreactors (316L, GMP compliant).
Energy/HVAC
- Boiler steam control, heat exchanger piping (high temperature and pressure resistant).
4. Customization Options
▸ Special threads: BSP, NPT, metric threads, etc. Custom processing.
▸ Drive upgrade: electric actuator (24VDC/220VAC), pneumatic explosion-proof head.
▸ Extreme working conditions:
- Deep cold treatment (-50℃ liquid nitrogen environment)
- Coating anti-corrosion (hydrofluoric acid resistance).
