1. Key Advantages
Zero Leakage Security
Self-adjusting sealing gland + PTFE seat, complying with ISO 5208 leakage standard, ensuring airtightness and eliminating the risk of media waste and pollution.
Ultra-low energy consumption drive
requires only 0.4~0.7MPa air pressure (40% energy saving compared with similar), single-acting spring reset design, automatic valve shutdown in case of air source failure, to ensure system safety.
360° flexible installation
pneumatic actuator can be rotated omnidirectionally, support horizontal/vertical pipeline installation at will, adapt to complex space layout; pneumatic control interface Namur standard, fast integration of solenoid valves/limit switches.
Full automation compatibility
Response time <0.2 seconds, support normally open/normally closed/double-acting control modes, high-frequency opening/closing (1000 times/hour), perfect match with PLC control system.
2. Technical Specifications (Technical Specifications)
|
Parameter items |
Standard configuration |
Extended options |
|
Body Material |
304/316 Stainless Steel (Ra≤0.8μm mirror polished) |
316L (Bio-Pharmaceutical Grade) |
|
Sealing Material |
PTFE (-30℃~+180℃) |
F46 (+220℃)/EPDM (Food Grade) |
|
Connection Method |
Flange (PN16-PN25) |
Threaded/Quick-fit/Welded |
|
Nominal Diameter |
DN15-DN100 |
DN125-DN150 (customized) |
|
Pressure Range |
0~16 bar (Vacuum to PN25) |
40 bar (High Pressure Type) |
|
Temperature Range |
-20℃~+200℃ (Standard) |
+300℃ (High Temperature) Sterilization) |
|
Actuator Type |
Single Acting (Spring Return) / Double Acting |
Explosion Proof / Manual Emergency Switch |
|
Protection Class |
IP65 |
IP68 (Submersible) |
|
Certification Standards |
ISO 9001 |
3-A, ASME BPE, FDA |
3. Industry Applications
High Temperature and High Pressure Scenarios
- Steam sterilization equipment (+180°C saturated steam), boiler system (PN25 pressure resistance)
- Chemical reactor heat transfer oil control (corrosion-resistant 316L valve body)
Food & Beverage & Pharmaceutical
- CIP/SIP pipeline aseptic transportation (mirror polishing Ra ≤ 0.8μm, through the FDA audit)
- Bioreactor media addition (zero dead space design, eliminating microbial residues)
Environmental protection and heavy industry
- Acid and alkali wastewater treatment valve sets (PTFE seals for strong corrosion resistance)
- Pneumatic conveying of viscous fluids/powders (high flow rate anti-clogging Y-shaped flow path)
Automated Manufacturing
- Laser cooling systems (high-frequency opening and closing), coating equipment (precise flow control)
- Air compressor piping (40% energy savings in air consumption, lower operating costs)
4. Customization Options
▸ Actuator Configuration**: Normally open (gas shut-off), Normally closed (gas open), Double-acting (need to stabilize the gas source)
▸ Intelligent Accessories:
- Limit switch (valve position feedback signal)
- Solenoid valve (24VDC/220VAC explosion-proof)
- Electrical positioner (4-20mA remote flow regulation)
▸ Special working condition adaption:
- Deep cold treatment (-50℃ liquid nitrogen environment)
- Coated valve stem (hydrofluoric acid corrosion resistance)
- Sanitary tri-clamp quick release (DIN/SMS standard)
